Kalex: the company with more motorcycle GP wins in past decade than any big name

'A Kalex chassis is just 1.2mm thick at some points, so it pings like a Coke can'

Browse pages
Current page

1

Current page

2

Current page

3

Current page

4

Current page

5

Current page

6

Current page

7

Current page

8

Current page

9

Current page

10

Current page

11

Current page

12

Current page

13

Current page

14

Current page

15

Current page

16

Current page

17

Current page

18

Current page

19

Current page

20

Current page

21

Current page

22

Current page

23

Current page

24

Current page

25

Current page

26

Current page

27

Current page

28

Current page

29

Current page

30

Current page

31

Current page

32

Current page

33

Current page

34

Current page

35

Current page

36

Current page

37

Current page

38

Current page

39

Current page

40

Current page

41

Current page

42

Current page

43

Current page

44

Current page

45

Current page

46

Current page

47

Current page

48

Current page

49

Current page

50

Current page

51

Current page

52

Current page

53

Current page

54

Current page

55

Current page

56

Current page

57

Current page

58

Current page

59

Current page

60

Current page

61

Current page

62

Current page

63

Current page

64

Current page

65

Current page

66

Current page

67

Current page

68

Current page

69

Current page

70

Current page

71

Current page

72

Current page

73

Current page

74

Current page

75

Current page

76

Current page

77

Current page

78

Current page

79

Current page

80

Current page

81

Current page

82

Current page

83

Current page

84

Current page

85

Current page

86

Current page

87

Current page

88

Current page

89

Current page

90

Current page

91

Current page

92

Current page

93

Current page

94

Current page

95

Current page

96

Current page

97

Current page

98

Current page

99

Current page

100

Current page

101

Current page

102

Current page

103

Current page

104

Current page

105

Current page

106

Current page

107

Current page

108

Current page

109

Current page

110

Current page

111

Current page

112

Current page

113

Current page

114

Current page

115

Current page

116

Current page

117

Current page

118

Current page

119

Current page

120

Current page

121

Current page

122

Current page

123

Current page

124

Current page

125

Current page

126

Current page

127

Current page

128

Current page

129

Current page

130

Current page

131

Current page

132

Current page

133

Current page

134

Current page

135

Current page

136

Current page

137

Current page

138

Current page

139

Current page

140

Current page

141

Current page

142

Current page

143

Current page

144

Current page

145

Current page

146

Current page

147

Current page

148

Current page

149

Current page

150

Current page

151

Current page

152

Current page

153

Current page

154

Current page

155

Current page

156

Current page

157

Current page

158

Current page

159

Current page

160

Current page

161

Current page

162

Current page

163

Current page

164

The most successful chassis designer in the MotoGP paddock doesn’t work for Ducati or Honda or Yamaha or any of the other big manufacturers. Alex Baumgärtel works for his own company, Kalex, which has dominated the intermediate Moto2 category for the past decade, winning an incredible 19 riders’ and constructors’ world championships and more than 140 grands prix.

Indeed Kalex has won more GP victories over the last ten years than Ducati, Suzuki and Yamaha combined.

Baumgärtel used to work in the car industry, at Holzer Motorsports, where he designed drivetrains and suspension for Opel DTM cars. However, he’s a motorcycle freak at heart, so around 15 years ago he started building race-bike chassis, just for fun, together with Holzer colleague and fellow bike enthusiast Klaus Hirsekorn.

Their first creation was an immediate success, winning races in Germany.

“We thought, ‘Hmm, maybe this thing isn’t so bad,’” Baumgärtel remembers. “So we said, ‘OK, let’s quit our jobs and try to survive in the motorcycle world.’”

In 2008 the pair established Kalex (a compound of their names Klaus and Alex), with no great aims of world domination. However, they were soon overtaken by events.

“We don’t like having the whole grid–we want to beat our rivals”

In 2010 MotoGP replaced the original 250cc intermediate class with Moto2, which specifies spec engines in prototype chassis. The idea was to reduce costs and encourage smaller constructors to return to GP racing.

“When the Moto2 regulations popped up, we said, ‘This is our chance – let’s invest all we’ve got,’” adds Baumgärtel.

The first Moto2 grid was mostly filled by established motorcycle chassis builders: garagiste enterprises like Bimota in Italy, Harris in the UK, Moriwaki from Japan and Suter from Switzerland. No one had heard of the newcomers from the small town Bobingen, near Munich. And yet one team, owned by former 250cc world champion Sito Pons, saw the promise and bought its frames and swingarms from Baumgärtel and Hirsekorn for Moto2’s inaugural season.

Kalex won the opening race of Moto2’s second season and has hardly stopped winning since. The only thing that’s prevented a full house of riders’ and constructors’ world titles over the past nine years is Marc Márquez, who won both crowns for Suter in 2012.

Baumgärtel has succeeded because he seems to understand the human aspect of motorcycle racing even better than people who have been into two wheels all their lives.

“I enjoy bikes because this black hole that the rider calls ‘feeling’ is super-interesting – you read the rider’s eyes to know if the bike is working or not,” he says. “Car racing is the complete opposite – it’s all data, more or less.”

How you translate the look in a rider’s eyes into a chassis CNC’d from 5083 aluminium alloy is the key to winning motorcycle races. Baumgärtel considers the whole motorcycle to be a kind of spring.

“During the last part of braking the rider is bending the forks and front wheel backwards by maybe half a millimetre, but that’s still a movement,” explains Baumgärtel. “Everything is stressed on the brakes, then the rider releases the brake, so everything relaxes and the wheel and forks move forward by the same amount. You need to control that spring-back in a friendly way.”

Until two decades ago constructors spent a lot of time chasing the assumed Holy Grail: the 100% stiff chassis. Only once they had the engineering capability to achieve that goal did they realise that frames and swingarms don’t work if they’re fully rigid.

“The front and back of the frame and swingarm are strong – you control the stiffness between those areas,” Baumgärtel continues.

Between the front and back of a Kalex chassis the aluminium is just 1.2mm thick at some points, so it pings like a Coke can. This allows the chassis to flex and twist in corners, which helps the tyres to track the asphalt better and the motorcycle to turn better.

And it’s not only the frame and swingarm. In racing, front-end feel is so vital to corner-entry speed and therefore lap times that Kalex offers different upper and lower triple clamps (which connect the front end to the frame) of varying stiffness.

Baumgärtel’s background at Holzer certainly helps, because the company not only works in the better-financed world of car racing but also in aerospace. Therefore his quality control is simply better than his rivals.

“Machining and fabricating are the key points, plus the guy who is doing the welding,” he says. “With high-precision machining we can have everything exactly the same, so we can build two bikes and the rider will get the same feeling from both. This didn’t use to happen. When we started, people told us that a rider could try two of our bikes and be unable to tell the difference, which they said was exceptional. I scratched my head and said, ‘Really?!’”

Kalex doesn’t only dominate the front positions of Moto2 racing – all but four of the 30 riders on this year’s grid will use Kalex chassis.
“We don’t like being called the Kings of Moto2 and we don’t like having nearly the whole grid, because we want to beat our rivals,” Baumgärtel says. “It’s a bittersweet feeling – we don’t want to be the destroyer but also we don’t want to lose!”


Mat Oxley has covered motorcycle racing for many years – and also has the distinction of being an Isle of Man TT winner
Follow Mat on Twitter @matoxley
